Name: RFD868+Modem
Brand: RFDesign
SKU: RFD868+Modem
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Home > Products > RF/IF and RFID > RF Modulators

RFDesign RFD868+Modem

Part No.:: RFD868+Modem

Manufacturer:: RFDesign

Category:: RF Modulators

Package:

Datasheet:: RFD868+Modem.pdf

Description:: Long-range radio data modem operating in the 902-928MHzor 865-870MHz frequency band

Quantity:: RFQ Add To RFQ list Buy Now Add To Cart

Unit Price:$0

Ext Price:$0

Product details

Details
Specifications
FAQ
Product Comparison
Related Categories

RFD868+Modem

Long-range radio data modem operating in the 902-928MHzor 865-870MHz frequency band

Features

• Out of the box RF communications. • Air data rate speeds of up to 500kbps

• Diversity antenna support • Weight of 14g

• Outdoor line-of-site range of up to 40km

• USART interface

• Status LEDs

Operational

• Operating voltage: 5V, I/O Voltage (3.3V)

• Temperature range: -40°C to +85°C

• Dimensions of 30mm x 57.7mm x12.8mm

• Current consumption:TX mode: ~1A peak at +30dBm, RX mode: 60mA (typical)

Applications

• Telemetry data

• UAV control

• Remote weather station

• House automation

• Long range RC

• Industrial and machine to machinecommunication

1 Key features

RFD900x provides compact and yet powerful data communication.

The key features are:

• No configuration required for out of the box RF communications.

• Operating frequency range of 902 – 928MHz or 865 - 870MHz

• Outdoor RF line-of-site range of 40km or more depending on antennas

• Air data rate speeds of up to 500kbps • Diversity antenna support

• Operating temperature of -40 to +85 degrees Celsius

• Dimensions of 30mm x 57mm x 12.8mm

• Weight of 14g

Compliances and Worldwide Acceptances:

The RFD900x modem is compliant to AS4268:2012, NZ GURL 2017, FCC 15.247 and RSS-247 Issue2.

Only the region locked versions of the modems are compliant.

The RFD868x modem is compliant to EN300220, EN301489, and EN62311, 865-867MHz unlicensedband in India.

Only the region locked versions of the modems are compliant

Software / GCS Support:
The software solution is an open source development called "SiK".

It has been re implemented to suit the new processor architecture available on the 32bit ARM processor core.

A boot loader and interface is available for further development and field upgrade of the modem firmware via the serial port.

Most parameters are configurable via AT commands, Eg. baud rate (air/uart), frequency band, power levels.

Integrated support for configuring the RFD900 radios is supported by APM Planner.

The default settings are at 57600 baud, N, 8, 1, and 64k air data rate.

The RFD868/900x manual is here: RFD900x Manual

The RFD868/900x SiK software manual is here : RFD900x Peer-to-peer Manual

Software features include:

Frequency hopping spread spectrum (FHSS)
Transparent serial link
Configuration by simple AT commands for local radio, RT commands for remote radio
User configurable serial data rates and air datarates
Mavlink protocol framing (user selectable)
Mavlink radio status reporting (Local RSSI, Remote RSSI, Local Noise, Remote Noise)
Automatic antenna diversity switching on a packet basis in realtime
Automatic duty cycle throttling based on radio temperature to avoid overheating
