Analog Devices Inc. ADG936BCPZ-RL

ADG936BCPZ-RL
Part No.:
ADG936BCPZ-RL
Manufacturer:
Analog Devices Inc.
Category:
RF Switches
Package:
20-WFQFN Exposed Pad, CSP
Datasheet:
Deyee Tech  LimitedADG936BCPZ-RL.pdf
Description:
W'BAND ABSORBTIVE/REFL'VE DUAL S
Quantity:

Unit Price:$0

Ext Price:$0

Product details

  • Details
  • Specifications
  • FAQ
  • Product Comparison
  • Related Categories

1. Functional Overview

The ADG936BCPZ-RL is a wideband dual SPDT (Single Pole Double Throw) RF switch from Analog Devices (ADI),

designed for high-frequency signal routing. Key features include:

  • Wideband operation: Supports frequencies up to 4 GHz with −3 dB bandwidth.

  • High isolation36 dB isolation at 1 GHz, minimizing signal leakage.

  • Low insertion loss0.9 dB (DC to 1 GHz), ensuring minimal signal degradation.

  • Low power consumption1 µA max, suitable for battery-powered and portable devices.

  • CMOS/LVTTL-compatible control logic: Simplifies integration with digital systems.

  • Dual SPDT configuration: Two independently controlled switches in a single package.

  • Packaging20-lead LFCSP (4×4 mm), optimized for compact PCB designs.

2. Key Applications

The ADG936BCPZ-RL is widely used in RF and wireless communication systems, including:

  • Antenna switching in MIMO (Multiple Input Multiple Output) and diversity receivers.

  • Transmit/Receive (T/R) switching in radar and wireless transceivers.

  • Signal routing in test & measurement equipment (e.g., spectrum analyzers, signal generators).

  • RF front-end modules in 4G/5G base stations and IoT devices.

  • General-purpose high-frequency signal switching in industrial and medical systems.

3. Similar Models & Alternatives

Several comparable RF switches from ADI and other manufacturers can serve as substitutes, depending on requirements:

Model Manufacturer Key Differences Substitution Level
ADG936BRUZ-REEL7 ADI TSSOP-20 package, same electrical specs Full replacement (different package)
ADG936BCPZ-RL7 ADI Similar specs, but tape-and-reel packaging Full replacement
ADG936BCPZ-R ADI Same specs but in tray packaging Full replacement
HMC472ALP4E ADI GaAs-based, wider frequency range (DC–3.8 GHz) Functional alternative (higher performance)
SKY13370-385LF Skyworks Similar SPDT RF switch, lower cost Functional alternative (check specs)[citation:N/A]

4. Selection Considerations

When choosing between ADG936BCPZ-RL and alternatives, consider:

  • Frequency range: Up to 4 GHz vs. other models (e.g., HMC472ALP4E supports 3.8 GHz).

  • Packaging: LFCSP (4×4 mm) vs. TSSOP (larger footprint).

  • Power supply1.65V–2.75V operation (low-voltage compatible).

  • Isolation & insertion loss: Critical for high-frequency applications

Packaging:
Tape & Reel (TR),Cut Tape (CT)
Series:
-
ProductStatus:
Active
RFType:
General Purpose
Topology:
Absorptive
Circuit:
2 x SPDT
FrequencyRange:
0Hz ~ 2GHz
Isolation:
36dB
InsertionLoss:
0.9dB
TestFrequency:
1GHz
P1dB:
16dBm
IIP3:
32dBm
Features:
Single Line Control
Impedance:
50Ohm
Voltage-Supply:
1.65V ~ 2.75V
OperatingTemperature:
-40°C ~ 85°C
Category:
RF Switches
Datasheet:
Deyee Tech  LimitedADG936BCPZ-RL.pdf
