Function of ADG1634BCPZ-REEL7

• Analog Switch Function: ADG1634BCPZ-REEL7 is an analog switch. It consists of four independently selectable Single-Pole Double-Throw (SPDT) switches.
• This configuration allows for the routing of analog signals between different paths.
• For example, it can be used to select between two input signals and route them to a single output, or vice versa, in each of the four channels.
• Power Supply Options: It supports both single and dual supply voltages. The single-supply voltage range is 3.3V to 16V,
• and the dual-supply voltage range is ±3.3V to ±8V. This flexibility in power supply makes it suitable for various circuit designs with different voltage requirements.
• Low On-Resistance and Flatness: The switch has an ultra-low on-resistance (with a maximum value specified, e.g., 4.5Ω or 10Ω
•  depending on different specifications sources) and good on-resistance flatness. This feature is crucial as it minimizes signal
• distortion and loss when the switch is in the on state, making it ideal for applications where signal integrity is important.
• Low Power Dissipation: Due to its ICMOS (Industrial CMOS) construction, it ensures ultra-low power dissipation.
• This characteristic is beneficial for portable and battery-powered instruments, as it helps to extend the battery life.
• Fast Switching Speeds: It has specified maximum turn-on and turn-off times. For example, at 5V,
• the maximum turn-on time is 90 ns and the maximum turn-off time is 256 ns.
• These fast switching speeds allow for quick signal routing and switching operations in circuits.
• Wide Operating Temperature Range: It can operate in a temperature range of -40°C to 125°C,
• making it suitable for use in various environmental conditions, including automotive and industrial applications where temperature variations can be significant.
• Logic Compatibility: It has 3V logic-compatible inputs and supports rail-to-rail operation.
• No VL supply is required, which simplifies the circuit design and interface with other logic circuits.

Applications of ADG1634BCPZ-REEL7

• Communication Systems: Used for signal routing and switching in communication equipment.
• For example, it can be employed to switch between different signal paths in radio frequency (RF) front-ends,
• or to route baseband signals in wired or wireless communication systems, helping to improve the performance and flexibility of the communication systems.
• Medical Systems: In medical instruments, it is used for signal processing. It can switch and route signals from various sensors (such as temperature sensors,
• pressure sensors, etc.) to the appropriate measurement and processing circuits.
•  The low distortion and high reliability of the switch ensure the accuracy of medical data acquisition and processing.
• Audio Signal Routing: Applied in audio equipment like audio mixers, amplifiers, etc.
• It can be used to switch between different audio input sources (such as microphones,
• line inputs, etc.) or route audio signals to different output channels (such as speakers, headphone jacks, etc.).
• The low on-resistance and low distortion characteristics help to maintain the high quality of audio signals.
• Video Signal Routing: Used in video systems, for example,
• in video switchers to select and route video signals from different sources (such as cameras, DVD players, etc.) to displays or recording devices.
•  Its ability to handle signals with low distortion is important for maintaining the visual quality of video.
• Automatic Test Equipment: In automatic test systems, it is used to switch test signals to different components or measurement points.
• The four independent SPDT switches allow for flexible configuration of test paths, enabling efficient testing of various electronic devices and circuits.
• Data Acquisition Systems: Ideal for data acquisition applications where low distortion is critical.
•  It can be used to switch between different input channels of a data acquisition module, allowing the module to sample signals from multiple sensors or sources.
• The low on-resistance and flatness ensure accurate signal acquisition.
• Battery-Powered Systems: Due to its low power dissipation,
• it is well-suited for battery-powered devices such as portable measurement instruments, handheld devices, etc.
• It helps to extend the battery life of these devices while still providing reliable signal switching functionality.
• Sample-and-Hold Systems: Can be used in sample-and-hold circuits to switch the input signal to the hold capacitor at the appropriate time.
•  The fast switching speeds and low on-resistance contribute to the accurate sampling and holding of signals.
• Relay Replacements: In some applications, it can replace mechanical relays. Compared to relays, it has faster switching speeds,
• longer lifespan, and lower power consumption. It can perform similar signal switching functions in circuits where relays were previously used,
• such as in control circuits and signal routing circuits.
