IC FPGA 316 I/O 484FBGA  XC6SLX45-3FGG484C

General Description

The Spartan®-6 family provides leading system integration capabilities with the lowest total cost for high-volume applications.

Thethirteen-member family delivers expanded densities ranging from 3,840 to 147,443 logic cells, with half the power consumption of previousSpartan families,

and faster, more comprehensive connectivity. Built on a mature 45 nm low-power copper process technology thatdelivers the optimal balance of cost, power, and performance,

the Spartan-6 family offers a new, more efficient, dual-register 6-input lookup table (LUT) logic and a rich selection of built-in system-level blocks.

These include 18 Kb (2 x 9 Kb) block RAMs, second generationDSP48A1 slices, SDRAM memory controllers, enhanced mixed-mode clock management blocks,

SelectIO™ technology, poweroptimized high-speed serial transceiver blocks, PCI Express® compatible Endpoint blocks, advanced system-level power managementmodes,

auto-detect configuration options, and enhanced IP security with AES and Device DNA protection.

These features provide a lowcost programmable alternative to custom ASIC products with unprecedented ease of use.

Spartan-6 FPGAs offer the best solution forhigh-volume logic designs, consumer-oriented DSP designs, and cost-sensitive embedded applications.

Spartan-6 FPGAs are theprogrammable silicon foundation for Targeted Design Platforms that deliver integrated software and

 hardware components that enabledesigners to focus on innovation as soon as their development cycle begins.

Key Features of XC6SLX45-3FGG484C:

1. FPGA Core & Logic Capacity:

   • 43,661 logic cells (43661 LUTs & flip-flops).

   • Spartan-6 LX Family (logic-optimized for cost efficiency).

   • Built on 45nm CMOS technology for low power consumption.

2. Memory & Storage:

   • 2,138,112 bits (267 KB) of block RAM (distributed as 148 × 18 Kb blocks).

   • Supports DDR3 memory interface (up to 800 Mbps).

3. High-Speed I/O & Interfaces:

   • 316 user I/O pins (supports multiple I/O standards like LVCMOS, LVDS, HSTL).

   • SelectIO™ technology for flexible voltage support (1.2V to 3.3V).

   • Gigabit Ethernet MAC (EMAC) for networking applications.

4. Clock Management:

   • Digital Clock Manager (DCM) & Phase-Locked Loops (PLLs) for precise timing control.

5. Power Efficiency:

   • 1.14V to 1.26V core voltage (low-power operation).

   • Zero-power suspend mode for ultra-low standby power.

6. Configuration & Security:

   • Supports AES encryption for secure bitstream loading.

   • Device DNA for unique FPGA identification.

7. Package & Temperature Range:

   • 484-pin FBGA (Fine-Pitch Ball Grid Array).

   • Commercial temperature range (0°C to 85°C).

Typical Applications:

1. Industrial Automation:

   • Motor control, PLCs (Programmable Logic Controllers), and robotics.

   • Real-time sensor data processing.

2. Consumer Electronics:

   • Digital displays, set-top boxes, and multimedia processing.

3. Communications & Networking:

   • Ethernet switches, routers, and protocol bridging.

4. Medical Devices:

   • Portable medical imaging and diagnostic equipment.

5. Automotive (Non-Automotive Grade Variant):

   • Infotainment systems (for non-safety-critical applications).

6. Test & Measurement:

   • High-speed data acquisition systems.

   •
