Name: KR2722-1
Brand: KR Electronics
SKU: KR2722-1
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Home > Products > Filters > RF Filters

KR Electronics KR2722-1

Part No.:: KR2722-1

Manufacturer:: KR Electronics

Category:: RF Filters

Package:

Datasheet:: KR2722-1.pdf

Description:: 98 MHz bandpass filter

Quantity:: RFQ Add To RFQ list Buy Now Add To Cart

Unit Price:$0

Ext Price:$0

Product details

Details
Specifications
FAQ
Product Comparison
Related Categories

General Description

KR 2722-1+ is a 98 MHz bandpass filter.

The filter has a minimum 3 dB bandwidth of 20 MHz (from 88 MHz to 108 MHz).

Other passband frequencies are available. Please consult thefactory.

Features

 Sharp Transition to Stopband

 60 dB Stopband

 Surface Mount Package

 50  Source and Load

Specifications

Parameter SpecificationFilter type BandpassCenter

Frequency 98 MHzInsertion Loss < 3 dB3 dB Bandwidth 20 MHz minAttenuation at 80 MHz > 60 dBA

ttenuation at 120 MHz > 60 dBSource and Load 50 
