The RK3588 is a high - performance SoC chip launched by Rockchip,

It has powerful functions and is widely used in many fields.

The following is an introduction to its functions and applications:

Functions

• Powerful Processing Power: The RK3588 adopts an 8 - core architecture, which is composed of 4
• Cortex - A76 large - cores with a main frequency of up to 2.4GHz and 4 Cortex - A55 small - cores with a main frequency of 1.8GHz.
• This Big.Little architecture can provide strong performance support for high - load tasks, and can also reduce power consumption in
• low - load situations, achieving a balance between performance and power consumption.
• Excellent Graphics Processing: It integrates the ARM Mali - G610 GPU, which has powerful graphics processing capabilities.
•  It supports at least 2 - way 4K UI, and can smoothly run complex graphics processing tasks and large - scale games. It supports the latest graphics APIs such as OpenGL ES 3.2 and Vulkan 1.2,
• and can also support multi - screen display technology, with a maximum of 4 - screen heterogeneous display.
• Powerful AI Computing Power: It integrates Rockchip's self - developed third - generation NPU (Neural Processing Unit) with a computing power of up to 6TOPS.
• It supports INT4/INT8/INT16/FP16 hybrid operations, and can efficiently run various deep - learning models, enabling complex AI tasks such as image recognition,
• speech recognition, and natural language processing. It also supports a variety of deep - learning frameworks, such as TensorFlow, PyTorch, and MXNet.
• Outstanding Multimedia Processing: It supports 8K@60fps H.265, 8K@30fps H.264 video hardware decoding, and 8K@30fps H.265/H.264 video hardware encoding,
• with wide compatibility. The integrated 48 - megapixel security - level ISP has rich functions such as HDR, 3DNR,
• and defogging, which can effectively improve the image quality and adapt to various complex lighting environments.
• Rich Interface and Expansion Capability: In terms of storage interfaces, it supports large - capacity storage interfaces such as eMMC and UFS,
• and also supports SD card expansion. In terms of network communication interfaces, it integrates an Ethernet interface and supports high - speed wired network connections.
• It also has a variety of other interfaces such as USB3.0 and PCIe, which can meet the connection and expansion needs of different devices.

Applications

• AI - powered Devices: It can be used in smart cameras, which can quickly and accurately identify faces, vehicles and other targets in the surveillance screen,
• and realize real - time monitoring and early warning. In smart robots, it can help robots understand the surrounding environment, make reasonable decisions, a
• nd complete complex tasks. It is also applicable to smart voice assistants, which can quickly process voice signals,
• realize voice interaction functions, and adapt to different accents and language environments.
• Multimedia Systems: It is widely used in media boxes, which can easily handle the playback and recording of ultra - high - definition videos,
• bringing users a cinema - level audio - visual experience. In digital signage, it can seamlessly render 4K videos, ensuring smooth content display.
•  It is also applicable to video - streaming platforms and video - conferencing applications, providing high - quality video and audio support.
• Automotive Applications: It is used in advanced driver - assistance systems (ADAS),
• which can process a large amount of data in real - time to help vehicles realize functions such as obstacle detection and lane departure warning.
•  It can also be used in in - car entertainment and navigation systems, providing smooth and responsive interfaces.
• Embedded Systems: Due to its high performance and flexibility, it is widely used in industrial automation,
• which can be used to control various industrial equipment and realize automated production processes.
• In smart home devices, it can be used as a control center to connect and manage various smart devices.
• It is also applicable to kiosks, providing users with a smooth interactive experience.
• Gaming Consoles: Its powerful GPU can easily meet the requirements of high - resolution and high - frame - rate game screens,
•  providing players with an immersive gaming experience, and is an ideal choice for gaming applications.
•


RK3588

Key features

• 8nm process, quad-core Cortex-A76 + quad-core Cortex-A55
• ARM Mali-G610 MC4 GPU, embedded high performance 2D image acceleration module
• 6.0 TOPs NPU, enable various AI applications
• 8K video codec ,8K@60fps display out
• Rich Display Interface, multi-screen display
• Super 32MP ISP with with HDR&3DNR, multi-camera inputs
• Rich high-speed interfaces (PCIe, TYPE-C,SATA, Gigabit ethernet)
• Android and Linux OS
• • Android and Linux OS

  SPECIFICATION
  CPU	• Quad core Cortex-A76 + Quad-core Cortex-A55
  GPU	• ARM Mali-G610 MC4
  	• OpenGL ES 1.1/2.0/3.1/3.2
  	• Vulkan 1.1,1.2
  	• OpenCL 1.1,1.2,2.0
  	• Embedded high performance 2D image acceleration module
  NPU	• 6TOPS NPU ,triple core, support int4/int8/int16/FP16/BF16/TF32 acceleration
  Video Codec	• H.265/H.264/AV1/AVS2 etc. multi video decoder, up to 8K@60fps
  	• 8K@30fps video encoders for H.264/H.265
  Display	• Built-in eDP/DP/ HDMI2.1/MIPI display interface,support multiple display engine max to 8K@60fps
  	• Supports multi-screen display with 8K60FPS max
  Video in and ISP	• Dual 16M Pixel ISP with HDR&3DNR
  	• Multiple MIPI CSI-2 and DVP interface, support HDMI 2.0 RX
  	• Support HDMI2.0 input with 4K60FPS max
  High speed interface	• PCIe3.0/PCIe2.0/SATA3.0/RGMII/TYPE-C/USB3.1/USB2.0
