MSP2TA-18-12+  Absorptive SPDT, Mechanical Switch, DC - 18000 MHz, 50Ω


Features of MSP2TA-18-12+

  • Type: Single-Pole Double-Throw (SP2T) coaxial switch

  • Frequency Range: DC to 18 GHz

  • Insertion Loss: 0.25 dB (typical)

  • Isolation: 80 dB (typical)

  • Power Handling: 10 dBm (≈10 mW)

  • Switching Speed: 20 ms (typical)

  • Voltage Supply: +12V DC

  • Configuration: Break-before-make (fault-safe design)

  • Package: Coaxial connector

  • Operating Temperature: -15°C to +45°C


Applications

  • Automatic Test Equipment (ATE): Signal routing in RF test systems

  • Microwave Radio Redundancy Switching: Backup path selection in communication systems

  • Military & Aerospace: Reliable switching in harsh environments

  • Satellite & Radar Systems: High-frequency signal management

  • Lab & R&D Prototyping: Flexible RF circuit testing


Similar Models

Model Type Frequency (GHz) Insertion Loss (dB) Isolation (dB) Power (dBm) Key Differences
MSP2T-18-12+ SP2T DC-18 0.25 80 10 Similar but non-absorbing fault protection
MSP2TA-18XL+ SP2T DC-18 0.25 80 10 Enhanced ruggedness (XL variant)
MSP4TA-18+ SP4T DC-18 0.25 85 2 Single-Pole 4-Throw (higher isolation)
USB-1SPDT-A18 SP2T DC-18 0.25 80 10 USB-controlled version
RC-1SPDT-A18 SP2T DC-18 0.25 80 10 Remote-controlled variant

Conclusion

The MSP2TA-18-12+ is a robust, high-isolation RF switch ideal for applications requiring reliable signal routing up to 18 GHz.

Similar models offer variations in control methods (USB/remote), throw configurations (SP4T),

and ruggedness (XL variants). For detailed datasheets,

consult Mini-Circuits' official documentation or distributors.Deyee Tech Limited
