D38999/20WE06SHA Circular MIL Spec Connector

About The Series 806The Series 806 Mil-Aero is anaerospace-grade micro miniaturecircular connector with triplestart threaded coupling.

The 806connector is smaller and lighter thanconventional aerospace connectors.Featuring size 22HD, 20HD contactsplus size 8 power and high speedEl Ochito®, quadrax, and fiber opticoptions.

The Series 806 offers up totwice the number of contacts withno reduction in performance thanMIL-DTL-38999 Series III.

In fact,independent laboratory testing hasdemonstrated that the Series 806meets, and in many cases exceeds, therequirements of MIL-DTL-38999.But there is more to the 806 thanjust size and weight reduction.

Thisflight-proven high-performanceconnector has many innovativefeatures that meet the most aggressiverequirements of the military/aerospaceindustry, including better resistance tovibration-induced decoupling.

This isaccomplished by re-engineering theratchet mechanism and introducing ashallower mating thread ramp anglethan is available in D38999.Glenair pioneered integral shieldbanding platforms to allow directattachment of cable shields,

boots andovermolds. This innovation continueswith the 806-Glenair's first connectorto exclusively use the ultra lightweightNano shield termination band formaximum size and weight reduction.

Another enhancement is a "tophat" insulator with raised bossesfor foolproof alignment of insulatorcavities and retention clips as well ashigher voltage ratings.

The Series 806 Mil-Aero connectorfeatures an O-ring radial interfacesealing design instead of a flat gasket.This allows for easier metal-to-metalcoupling, improved sealing, and betterEMI performance.

The MIL-DTL-38999Series III and other legacy aerospacecircular connectors have a flat gasketinside the receptacle shell. Thisperipheral seal must be compressedsufficiently to allow full metal-tometal connector bottoming. In certaintolerance conditions this seal can makeit difficult to fully mate the connectors"without the use of tools" as is requiredby MIL-DTL-38999.
