Deyee Tech Limited - Global Electronic Component Distributor | IC, Aerospace, Automotive Electronics

Name: AP1084D18LA
Brand: ANACHIP
SKU: AP1084D18LA
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Home > Products > Integrated Circuits (ICs) > PMIC - Voltage Regulators - Linear Regulator Controllers

ANACHIP AP1084D18LA

Part No.:: AP1084D18LA

Manufacturer:: ANACHIP

Category:: PMIC - Voltage Regulators - Linear Regulator Controllers

Package:

Datasheet:: AP1084D18LA.pdf

Description:: 5A Low Dropout Positive Adjustable or Fixed-Mode Regulator

Quantity:: RFQ Add To RFQ list Buy Now Add To Cart

Unit Price:$0

Ext Price:$0

Product details

Details
Specifications
FAQ
Product Comparison
Related Categories

AP1084D18LA is a low-dropout (LDO) positive voltage regulator with adjustable or fixed output modes,

designed for power management in various electronic devices. Below are its functions and applications in detail:

Functions

Low Dropout Voltage
- Maximum dropout voltage of 1.4V at full load current, making it suitable for low input voltage applications.
High Output Current
- Supports up to 5A output current, capable of meeting high-power load requirements.
Adjustable or Fixed Output Voltage
- Offers adjustable output mode (1.25V to 3.3V) or fixed output voltage options (1.5V, 1.8V, 2.5V, 3.3V, 5.0V), catering to different circuit design needs.
Built-in Protection Features
- Includes thermal shutdown and output current limiting to ensure safe operation under abnormal conditions.
Fast Transient Response and Low Noise
- Suitable for applications requiring high power stability, such as high-speed buses and low-noise circuits.
Multiple Package Options
- Available in TO-252, TO-263, TO-220, and PDIP-8 packages, providing flexibility for various design requirements.

Applications

High-Speed Bus Termination Power Supply
- Provides stable low-voltage power for high-speed buses, ensuring reliable signal transmission.
Low-Voltage Logic Circuit Power Supply
- Ideal for powering 3.3V logic circuits, such as microcontrollers and digital signal processors.
Graphics Card (VGA Card) Power Management
- Delivers stable power to graphics cards, ensuring high-performance graphics processing.
Communication Equipment
- Used in wireless communication modules, networking devices, and other scenarios requiring efficient power management.
Industrial Control and Automation
- Provides stable power to sensors, actuators, and other devices in industrial control systems.
Consumer Electronics
- Suitable for power management in TVs, set-top boxes, routers, and other consumer electronic devices.

Technical Parameters

Input Voltage Range: 4.7V to 12V.
Output Voltage: Adjustable (1.25V to 3.3V) or fixed (1.5V, 1.8V, 2.5V, 3.3V, 5.0V).
Package Options: TO-252, TO-263, TO-220, PDIP-8.

Summary

The AP1084D18LA is a high-performance LDO regulator suitable for various low-voltage, high-current power management scenarios. Its low dropout voltage,

high output current, and multiple protection features make it widely applicable in industrial, communication, and consumer electronics fields.

For more detailed technical parameters or supplier information, please refer to the relevant datasheet or contact the supplier directly.

Packaging:

Series:

ProductStatus:

Type:

NumberofOutputs:

Current-Supply:

Voltage-Input:

OperatingTemperature:

VRRM(V):

I(AV)(A):

IFSM(A):

Category:: PMIC - Voltage Regulators - Linear Regulator Controllers

Datasheet:: AP1084D18LA.pdf
