Analog Devices Inc. HMC641ALP4E

HMC641ALP4E
Part No.:
HMC641ALP4E
Manufacturer:
Analog Devices Inc.
Category:
RF Switches
Package:
24-VFQFN Exposed Pad
Datasheet:
Deyee Tech  LimitedHMC641ALP4E.pdf
Description:
IC RF SWITCH SP4T 20GHZ 24SMT HMC641ALP4E
Quantity:

Unit Price:$0

Ext Price:$0

Product details

  • Details
  • Specifications
  • FAQ
  • Product Comparison
  • Related Categories

IC RF SWITCH SP4T 20GHZ 24SMT HMC641ALP4E


FEATURES

Broadband frequency range: 0.1 GHz to 20 GHz

Nonreflective 50 Ω designLow insertion loss: 3.0 dB at 20 GHz

High isolation: 40 dB at 20 GHzHigh input linearity at 250 MHz to 20 GHzP1dB: 24 dBm typicalIP3: 41 dBm typical

High power handling26.5 dBm through path23 dBm terminated pathIntegrated 2 to 4 line decoder24-lead, 4 mm × 4 mm LFCSP package

ESD rating: 250 V (Class 1A)

APPLICATIONS

Test instrumentationMicrowave radios and very small aperture terminals (VSATs)

Military radios, radars, and electronic counter measures (ECMs)Broadband telecommunications systems

Packaging:
Strip
Series:
-
ProductStatus:
Active
RFType:
VSAT
Topology:
Absorptive
Circuit:
SP4T
FrequencyRange:
0Hz ~ 20GHz
Isolation:
40dB
InsertionLoss:
3dB
TestFrequency:
20GHz
P1dB:
24dBm
IIP3:
41dBm
Features:
-
Impedance:
50Ohm
Voltage-Supply:
-
OperatingTemperature:
-40°C ~ 85°C
Category:
RF Switches
Datasheet:
Deyee Tech  LimitedHMC641ALP4E.pdf
