MEAN WELL USA Inc. DET01L-05

Part No.:: DET01L-05

Manufacturer:: MEAN WELL USA Inc.

Category:: Uncategorized

Package:

Datasheet:: DET01L-05.pdf

Description:: 1W unregulated dual-output DC-DC converter

Quantity:: RFQ Add To RFQ list Buy Now Add To Cart

Unit Price:$0

Ext Price:$0

Product details

Details
Specifications
FAQ
Product Comparison
Related Categories

The DET01L-05 is a 1W unregulated dual-output DC-DC converter manufactured by MEAN WELL,

designed for applications requiring isolated power conversion with compact SMD packaging.

Below is an overview of its key features and applications in English:

Key Features of DET01L-05

Dual Unregulated Outputs
- Provides ±5V outputs with ±100mA current capacity per channel.
- Non-regulated design, meaning output voltage varies slightly with load and input changes.
High Isolation & Safety Compliance
- 3000VDC I/O isolation, ensuring protection against high-voltage surges.
- RoHS compliant, lead-free construction.
- Meets safety standards such as UL60950-1 and CSA C22.2.
Compact SMD Design
- Surface-mountable (SMD) package (15.2mm × 7.5mm × 6.5mm).
- Efficiency up to 78%, reducing power loss in small-form-factor applications.
Wide Operating Conditions
- Input voltage range: 4.5V to 5.5V.
- Operating temperature: -40°C to +85°C (with derating).
- Short-circuit protection (SCP) and overload protection (OCP) for reliability.
Low Noise & Ripple
- Max ripple & noise: 100mVp-p (measured at 20MHz bandwidth).
- Switching frequency: 100kHz, reducing interference in sensitive circuits.

Applications

Industrial Control Systems: Used in PLCs, sensors, and automation equipment requiring isolated power.
Telecommunications & Networking: Provides dual-rail power for data switches, routers, and wireless modules.
Test & Measurement Equipment: Suitable for oscilloscopes, analyzers, and probes needing ±5V supply.
Medical & Laboratory Instruments: Ensures safe power isolation in diagnostic devices.
