STMicroelectronics STL120N2VH5

STL120N2VH5
Part No.:
STL120N2VH5
Manufacturer:
STMicroelectronics
Category:
Transistors - FETs, MOSFETs - Single
Package:
PowerFlat™ (5x6)
Datasheet:
Deyee Tech  LimitedSTL120N2VH5.pdf
Description:
MOSFET N-CH 20V 120A POWERFLAT
Quantity:

Unit Price:$0

Ext Price:$0

Product details

  • Details
  • Specifications
  • FAQ
  • Product Comparison
  • Related Categories
Packaging:
Tape & Reel (TR),Cut Tape (CT)
Series:
STripFET™ V
ProductStatus:
Obsolete
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
20 V
Current-ContinuousDrain(Id)@25°C:
120A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
2.5V, 4.5V
RdsOn(Max)@IdVgs:
3mOhm @ 14A, 4.5V
Vgs(th)(Max)@Id:
700mV @ 250µA (Min)
GateCharge(Qg)(Max)@Vgs:
29 nC @ 2.5 V
Vgs(Max):
±8V
InputCapacitance(Ciss)(Max)@Vds:
4660 pF @ 15 V
FETFeature:
-
PowerDissipation(Max):
80W (Tc)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
Category:
Transistors - FETs, MOSFETs - Single
Datasheet:
