onsemi NBC12439AFNG

Part No.:: NBC12439AFNG

Manufacturer:: onsemi

Category:: The Posts

Package:: 28-LCC (J-Lead)

Datasheet:: NBC12439AFNG.pdf

Description:: IC CLOCK SYNTH 50-800MHZ 28-PLCC

Quantity:: RFQ Add To RFQ list Buy Now Add To Cart

Unit Price:$0

Ext Price:$0

Product details

Details
Specifications
FAQ
Product Comparison
Related Categories

Description

The NBC12439 and NBC12439A are general purpose, PLL based synthesized clock sources. The VCO will operate over a frequency range of 400 MHz to 800 MHz. The VCO frequency is sent to the N−output divider, where it can be configured to provide division ratios of 1, 2, 4 or 8. The VCO and output frequency can be programmed using the parallel or serial interfaces to the configuration logic. Output frequency steps of 16 MHz, 8 MHz, 4 MHz, or 2 MHz can be achieved using a 16 MHz crystal, depending on the output divider settings. The PLL loop filter is fully integrated and does not require any external components.

Features
• Best−in−Class Output Jitter Performance, ±20 ps Peak−to−Peak
• 50 MHz to 800 MHz Programmable Differential PECL Outputs
• Fully Integrated Phase−Lock−Loop with Internal Loop Filter
• Parallel Interface for Programming Counter and Output Dividers During Powerup
• Minimal Frequency Overshoot
• Serial 3−Wire Programming Interface
• Crystal Oscillator Inputs 10 MHz to 20 MHz
• Operating Range: VCC = 3.135 V to 5.25 V
• CMOS and TTL Compatible Control Inputs
• Pin and Function Compatible with Motorola MC12439 and MPC9239
• Powerdown of PECL Outputs ( 16)
• 0°C to 70°C Ambient Operating Temperature (NBC12439)
• −40°C to 85°C Ambient Operating Temperature (NBC12439A)

• Pb−Free Packages are Available

onsemi NBC12439AFNG

Package/Case:: 28-LCC (J-Lead)

Packaging:: Tube,Tube

Series:: -

ProductStatus:: Obsolete

Type:: PLL Clock Generator

PLL:: Yes

Input:: Crystal

Output:: PECL

NumberofCircuits:: 1

Ratio-Input:Output:: 1:1

Differential-Input:Output:: No/Yes

Frequency-Max:: 800MHz

Divider/Multiplier:: Yes/No

Voltage-Supply:: 3.135V ~ 5.25V

OperatingTemperature:: -40°C ~ 85°C

MountingType:: Surface Mount

Category:: The Posts

Datasheet:: NBC12439AFNG.pdf
