Diodes-Rectifiers-Single
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CFRM105-HFDIODE GEN PURP 600V 1A MINISMA |
2,279 | 0.14 |
|
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 15pF @ 4V, 1MHz | 250 ns | 5 µA @ 600 V | 600 V | 1A (DC) | -55°C ~ 150°C | 1.3 V @ 1 A | |
|
CDBB340-GDIODE SCHOTTKY 40V 3A DO214AA |
3,305 | 0.14 |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Not For New Designs | Surface Mount | - | - | 500 µA @ 40 V | 40 V | 3A | 125°C (Max) | 500 mV @ 3 A | |
|
CFRMT104-HFDIODE GEN PURP 400V 1A SOD123H |
2,006 | 0.14 |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 250 ns | 5 µA @ 400 V | 400 V | 1A | -55°C ~ 150°C | 1.3 V @ 1 A | |
|
CDBB1200LR-HFDIODE SCHOTTKY 200V 1A DO214AA |
2,033 | 0.14 |
|
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 120pF @ 4V, 1MHz | - | 500 µA @ 200 V | 200 V | 1A | -50°C ~ 175°C | 850 mV @ 1 A | |
|
RS3BC-HFRECTIFIER FAST RECOVERY 100V 3A |
2,583 | 0.14 |
|
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | 150 ns | 5 µA @ 100 V | 100 V | 3A | -55°C ~ 150°C | 1.3 V @ 3 A | ||
|
|
RS3AC-HFRECTIFIER FAST RECOVERY 50V 3A S |
2,776 | 0.14 |
|
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | 150 ns | 5 µA @ 50 V | 50 V | 3A | -55°C ~ 150°C | 1.3 V @ 3 A | ||
|
|
RS3KC-HFRECTIFIER FAST RECOVERY 800V 3A |
3,496 | 0.14 |
|
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | 500 ns | 5 µA @ 800 V | 800 V | 3A | -55°C ~ 150°C | 1.3 V @ 3 A | ||
|
|
RS3JC-HFRECTIFIER FAST RECOVERY 600V 3A |
3,449 | 0.14 |
|
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | 250 ns | 5 µA @ 600 V | 600 V | 3A | -55°C ~ 150°C | 1.3 V @ 3 A | ||
|
|
RS3GC-HFRECTIFIER FAST RECOVERY 400V 3A |
2,071 | 0.14 |
|
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | 150 ns | 5 µA @ 400 V | 400 V | 3A | -55°C ~ 150°C | 1.3 V @ 3 A | ||
|
|
RS3DC-HFRECTIFIER FAST RECOVERY 200V 3A |
2,309 | 0.14 |
|
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | 150 ns | 5 µA @ 200 V | 200 V | 3A | -55°C ~ 150°C | 1.3 V @ 3 A | ||
|
|
RS3MC-HFRECTIFIER FAST RECOVERY 1000V 3A |
3,237 | 0.14 |
|
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | 500 ns | 5 µA @ 1000 V | 1000 V | 3A | -55°C ~ 150°C | 1.3 V @ 3 A | ||
|
|
US5DC-HFRECTIFIER ULTRA FAST RECOVERY 20 |
2,725 | 0.14 |
|
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 50pF @ 4V, 1MHz | 50 ns | 5 µA @ 200 V | 200 V | 5A | -55°C ~ 150°C | 1 V @ 5 A | |
|
|
US5JC-HFRECTIFIER ULTRA FAST RECOVERY 60 |
2,646 | 0.14 |
|
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 50pF @ 4V, 1MHz | 75 ns | 5 µA @ 600 V | 600 V | 5A | -55°C ~ 150°C | 1.65 V @ 5 A | |
|
|
US5MC-HFRECTIFIER ULTRA FAST RECOVERY 10 |
3,738 | 0.14 |
|
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 50pF @ 4V, 1MHz | 75 ns | 5 µA @ 1000 V | 1000 V | 5A | -55°C ~ 150°C | 1.65 V @ 5 A | |
|
|
US5AC-HFRECTIFIER ULTRA FAST RECOVERY 50 |
3,283 | 0.14 |
|
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 50pF @ 4V, 1MHz | 50 ns | 5 µA @ 50 V | 50 V | 5A | -55°C ~ 150°C | 1 V @ 5 A | |
|
|
US5BC-HFRECTIFIER ULTRA FAST RECOVERY 10 |
3,204 | 0.14 |
|
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 50pF @ 4V, 1MHz | 50 ns | 5 µA @ 100 V | 100 V | 5A | -55°C ~ 150°C | 1 V @ 5 A | |
|
|
US5GC-HFRECTIFIER ULTRA FAST RECOVERY 40 |
3,237 | 0.14 |
|
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 50pF @ 4V, 1MHz | 50 ns | 5 µA @ 400 V | 400 V | 5A | -55°C ~ 150°C | 1.3 V @ 5 A | |
|
|
US5KC-HFRECTIFIER ULTRA FAST RECOVERY 80 |
2,676 | 0.14 |
|
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 50pF @ 4V, 1MHz | 75 ns | 5 µA @ 800 V | 800 V | 5A | -55°C ~ 150°C | 1.65 V @ 5 A | |
|
|
CDBB1150LR-HFDIODE SCHOTTKY 150V 1A DO214AA |
2,433 | 0.14 |
|
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 120pF @ 4V, 1MHz | - | 500 µA @ 150 V | 150 V | 1A | -50°C ~ 175°C | 820 mV @ 1 A | |
|
CDBA3100LR-HFDIODE SCHOTTKY 100V 3A DO214AC |
2,746 | 0.17 |
|
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 250pF @ 4V, 1MHz | - | 500 µA @ 100 V | 100 V | 3A | -50°C ~ 150°C | 750 mV @ 3 A |
